Note: Please press C key firstly when you using remote control, thanksSpecifications Input: USB / Optical / Coaxial / Bluetooth Output: RCA /XLR THD+N: 000090(-121dB) Dynamic range: XLR/130dB ;RCA/123dB Output impedance: XLR 207Ω; RCA 142Ω USB transmission : Asynchronization USB compatibility: Windows 7+, Mac OSX、Linux Bit depth: USB 1bit, 16~32bit; Optical/ Coaxial 1bit, 16~ 24bit Sampling rate: USB PCM 44.1 ~ 768kHz; DSD 2.8224 ~ 22.5792MHz ; Optical / Coaxial PCM 44.1 ~ 192kHz; DSD DSD64(DoP) Bluetooth specification: UAT: 24bit/192kHz (1 200kbps/900kbps/600kbps) LDAC: 24bit/96kHz (990kbps/660kbps/330kbps) aptX-HD: 24bit/48 kHz_ _576kbps aptX: 16bit/44.1 kHz_ 352kbps SBC: 16bit/44.1 kHz_ 328kbps AAC: 16bit/44.1 kHz_ 320kbps Power Consumption: 5W Standby power: <0.5W Size: 187.5*154*40MM(W*H*D) Weight: 0.79kg Contents List SU-9*1 REMOTE*1 USB CABLE*1 POWER CABLE*1 USER GUIDE*1
Complete support of LDAC,APTX/HD,XBC,AAC, and the exquisite 24bit/192kHz UAT format
Apart from ES9038 flagship DAC we coupled this DAC with ES9311 power chip designed for ESS DACS to optimize ES9038 performance to its max potential.
All digital inputs support DSD decoding. DoP64 is supported through coaxial and optic.
The power source is implemented with shielded low noise conditioner. This improves both sound quality and power efficiency.
UAT (Ultra Audio Transmission), an audio coding technology self-developed by HiBy with up to 192kHz sampling frequency or up to 1.2Mbps bit rate. There are three available settings: high 1.2Mbps/medium 900 kbps/low 600 kbps.
